Globe Valve, Pressure Seal Globe Valve

Coosai globe valves is used in class 150～class 2500, NPS ½～NPS 12, working temperature -196℃～540℃ many
kinds of pipelines, and can be applicable to water, steam, oil and so on. Via choosing different types of materials.

Applicable Standards

Design Standard: BS1873, ASME B16.34,DIN 3356,API602

Structure: Bolted Bonnet, Welded bonnet, Pressure seal ,Outside screw & yoke,”Y” pattern, Special design for Fugitive emission testing

Material: DI, CS, SS, DSS,LTCS, Inconel ,Monel, Bronze,Aluminum Bronze

Operation type: Manual, Electric Actuator, Pneumatic Actuator, Hydraulic actuator

Nominal Dimension: Casting Valve: 2”-12”, Forging Valve: 1/4"~2"

Nominal Pressure: Class 150-2500

Connection type: RF,RTJ,FF, SW, NPT, BW

Company Introduction

Coosai a specialized valve manufacturer which has 30 years’ experience in the design and manufacturing of quality engineered valves.

Coosai has a sound organization structure, professional technical capacity, advanced manufacturing and testing equipment, rigorous quality control system and well trained service staff. There is a real technical proficiency at Coosai with an organization to produce and supply valves according to any specific requirements the customer may ask.

Coosai workshops cover an area of 12000 square meters. Total registered asset is RMB 80 million. Besides ISO9001:2008 quality management and QC system, Coosai has the capability in offering varied products by virtue of over 100 sets large scale CNC lathes, testing equipment and computerized control valve testing and calibration bench. Nondestructive testing equipment include PT,UT,MT and RT are available.

Coosai produces quality Ball Valve, Gate valve, Globe valve and Check Valve, Knife gate valve and Segment Ball Valve, Control valves and Butterfly Valves. Valve size from 1/2”—60”,pressure from 150LB-2500LB,temperature range from -196ºC to 610 ºC, connected with manual, pneumatic, electric, hydraulic operator etc.

Coosai valves are CE PED 97/23/EEC, API 6D-0749, API6A-1199,API607 (fire safe) and TS certified. Coosai is Tier One supplier for SINOPEC and CNPC.

Coosai is dedicated to offering the best configuration and satisfy client’s expectations and their eventual commitments.

We look forward to meeting all distinguished clients and industry experts and sincerely welcome all your valuable inquiries.
